PW049-AAB
Front-Facing Cleaning Head for Fast Cycles and Flat Surfaces
The PW049-AAB front-facing cleaning head is designed to perform fast and targeted cleaning on flat surfaces, where it is essential to maintain close spray targets and short cycle times. It is an ideal solution for applications such as car wash systems and open waste containers, where speed, uniform coverage, and configuration flexibility make a real difference.
This model is widely used in the car wash and waste collection sectors, where cleaning cycles must be efficient, repeatable, and easily adaptable to different surfaces and geometries.
Type
Sector
Self-rotating head with flow priority and side delivery. Nozzle holder: 6 different working angles.
Acquamotor
Certification
Motor
Why choose the PW049-AAB
The PW049-AAB is engineered to cover flat surfaces with continuous and close cleaning action thanks to its high-speed mono-axial rotation.
This allows the jet to concentrate its action uniformly on the target area, reducing cleaning time and increasing system productivity.
One of the key strengths of this model is its configuration flexibility.
The many available nozzle combinations allow the cleaning pattern to be adapted to specific operational needs without replacing the machine.
The PW049-AAB is ideal for users who:
- require short cleaning cycles
- need to treat flat or open surfaces
- want a versatile and easily configurable cleaning head
Concrete advantages for the operator
- Close cleaning targets ensuring uniform surface coverage
- Fast cleaning cycles, ideal for high-frequency applications
- High flexibility thanks to multiple nozzle configurations
- System adaptability with lateral or axial feed connection
- High reliability even under intensive use
Main technical features
- Lateral or axial feed connection
- Flow rate up to 30 l/min
- Operating pressure up to 150 bar
- Up to 12 possible combinations of cone nozzles
- High rotation speed
- Mono-axial rotation
Installation, maintenance and certifications
The PW049-AAB can be easily integrated into existing systems and does not require complex modifications.
It is designed for long-term reliability and requires only standard maintenance of wear components.
Available on request:
- CE certification
- ATEX certification
If you are looking for a front-facing cleaning head that combines speed, precision, and configuration flexibility, the PW049-AAB is a practical and efficient solution.
The Bolondi team is available to support you in selecting the most suitable configuration or developing customized solutions based on your specific operational requirements.
Product details | |
|---|---|
Water inlet | 3/8″ G |
Nozzles | 1/8″ NPT |
Materials | Seals: NBR; AISI 316 – Aluminum |
Inlet hole | – |
Rotation speed | 100 ÷ 200 rpm |
Weight | 3 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 150 bar |
Flow rate | 15 - 30 l/min |
Product details | |
|---|---|
Water inlet | 3/8″ G |
Nozzles | 1/8″ NPT |
Materials | Seals: NBR; AISI 316 – Aluminum |
Inlet hole | – |
Rotation speed | 100 ÷ 200 rpm |
Weight | 3 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 150 bar |
Flow rate | 15 - 30 l/min |
