PW060-LC
Acquamotor
PW060-LC
Flexible Front-Facing Cleaning Head for Large Surfaces
The PW060-LC front-facing cleaning head is designed to perform effective and controlled frontal cleaning on large flat surfaces. Thanks to its configuration with two arms with a customizable total length of up to 1 meter, it offers high operational flexibility and is particularly suitable for close-range cleaning and applications involving wide surface areas.
The PW060-LC is successfully used in railway washing systems, car wash installations, conveyor belt cleaning, and construction machinery washing. It is particularly well suited for the car wash sector and heavy industry, where robustness and adaptability are essential requirements.
Type
Sector
Self-rotating head with flow-priority design and side inlet. It can operate at low or high rotational speeds and can be configured with 2, 3, or 4 arms of varying lengths, with bends at different angles according to customer requirements.
Acquamotor
Certification
Motor
Why choose PW060-SL_CF/SF
The key strength of the PW060-SL_CF/SF lies in its ability to precisely define the impact area of the cleaning jets, thanks to the modular arms and optional elbows. This configuration ensures effective operation across surfaces of varying sizes, maintaining a controlled and uniform cleaning impact.
The adjustable rotation speed, configurable according to operational requirements, allows selection between faster cleaning cycles or more controlled interventions, increasing the versatility of the cleaning head across different industrial applications.
It is designed for operators who
- work on large or variable flat surfaces
- require controlled, close-range cleaning performance
- need a highly configurable front-facing cleaning solution
Key Benefits
- Four modular arms for maximum configuration flexibility
- Adaptability to flat surfaces of different sizes
- Adjustable rotation speed based on process requirements
- Precise control of the jet impact area
- Optional water filtration system for enhanced equipment protection
Main Technical Features
- Lateral or axial inlet connection
- Flow rate up to 60 l/min
- Operating pressure up to 200 bar
- Modular arms and/or elbows to define the cleaning impact area
- Selectable rotation speed: high or low
- Adjustable single-axis rotation from 5 to 16 rpm
Installation, Maintenance and Certifications
The PW060-SL_CF/SF is easy to integrate into existing industrial cleaning systems and does not require complex installation procedures.
It is designed to ensure long-term reliability and requires only standard maintenance of wear components.
Available upon request:
- CE certification
- ATEX certification
If you require a modular, flexible, and highly configurable front-facing cleaning head for large surfaces and close-range industrial cleaning, the PW060-SL_CF/SF provides a complete and versatile solution.
The Bolondi team is available to support you in defining the optimal configuration or developing custom solutions based on your specific operational requirements.
Product details | |
|---|---|
Water inlet | 1/2″ |
Nozzles | 1/4″ NPT |
Materials | Seals: NBR – EPDM – VITON; AISI 316 – Aluminum |
Inlet hole | Variable depending on arm configuration |
Rotation speed | 20 ÷ 120 rpm |
Weight | 3 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 200 bar |
Flow rate | 8 - 60 l/min |
Product details | |
|---|---|
Water inlet | 1/2″ |
Nozzles | 1/4″ NPT |
Materials | Seals: NBR – EPDM – VITON; AISI 316 – Aluminum |
Inlet hole | Variable depending on arm configuration |
Rotation speed | 20 ÷ 120 rpm |
Weight | 3 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 200 bar |
Flow rate | 8 - 60 l/min |
