The RT611-ASA is designed to deliver controlled dynamic cleaning, with real-time process monitoring enabled by open/closed position sensors and a rotation sensor.

 This ensures:

• effective cleaning control even in distributed systems
• seamless integration into critical process environments
• precise monitoring of movement and operating status

During production, the head fully retracts, eliminating any internal protrusion.

 The integrated position and rotation sensors allow full integration into automation and control systems, enhancing both operational safety and process traceability.

It is the ideal solution for operators who:

• require flush-mounted installation compliant with cGMP standards
• cannot allow any interference with the product during processing
• need monitoring of cleaning head position and rotation

• Flush-mounted installation with no product interference
• Actuation via pressurized water
• Integrated sensors for position and rotation monitoring
• Simple design with minimal components

The main advantage compared to conventional solutions is its ability to fully retract during production while maintaining high levels of control and operational safety.

• Radial inlet connection
• Water-driven actuation with spring return mechanism
• Position sensors (open/closed) and rotation sensor
• Flow rate up to 31 l/min
• Operating pressure up to 8 bar
• Designed for integration into pipelines and process equipment

The RT611-ASA is easy to integrate during the design or modification phase of the system.

 It is not easily retrofitted on fully completed equipment, therefore a preliminary technical evaluation is recommended.

Thanks to its minimal component design, maintenance requirements are very low and limited to standard inspection of wear parts.

Supplied with:

• CE certification

If you are looking for a linear motion retractable cleaning head with integrated sensors, cGMP-compliant installation, and advanced process control, the RT611-ASA provides a highly integrated and reliable technical solution.

The Bolondi team is available to support you in evaluating proper system integration or developing custom solutions based on your specific production requirements.
