RW200A

Acquamotor

High Flow Volumetric Self-Rotating Tank Cleaning Head for Large Tanks and Vessels

RW200A

High Flow Volumetric Self-Rotating Tank Cleaning Head for Large Tanks and Vessels

The RW 200A is a volumetric self-rotating cleaning head designed for cleaning medium and large tanks, vessels, and IBC containers, as well as internal components of industrial equipment. It is engineered for demanding applications where high flow rate, high pressure, and operational reliability are required.


It is ideally suited for the chemical industry and heavy industrial applications, particularly for cleaning large-volume tanks and storage vessels.

Type

Internal

The RW 200A is a volumetric self-rotating cleaning head designed for cleaning medium and large tanks, vessels, and IBC containers, as well as internal components of industrial equipment. It is engineered for demanding applications where high flow rate, high pressure, and operational reliability are required.
It is ideally suited for the chemical industry and heavy industrial applications, particularly for cleaning large-volume tanks and storage vessels.

Acquamotor

Certification

Motor

Why choose RW 200A

The RW 200A delivers highly effective volumetric cleaning thanks to its low rotational speed, allowing the jets to dwell longer on internal surfaces and improve cleaning performance. The option to configure the unit with 2 or 4 nozzles provides flexibility to match specific application requirements.


With flow rates up to 200 l/min and operating pressures up to 200 bar, it is designed to perform reliably even in severe working conditions, ensuring high efficiency on large surface areas.


It is the ideal solution for operators who:

  • need to clean large tanks and vessels
  • require high flow rate combined with high pressure
  • operate in heavy-duty industrial environments

Concrete advantages for the operator

  • Effective volumetric cleaning due to low rotational speed
  • Flexible configuration with 2 or 4 nozzles
  • High flow rate up to 200 l/min
  • Operating pressure up to 200 bar
  • Robust and reliable construction for severe applications
  • High application versatility

The RW 200A provides an optimal combination of power and control, making it suitable for a wide range of industrial cleaning processes.

Main Technical Features

  • Axial inlet connection
  • Pump flow rate up to 200 l/min
  • Operating pressure up to 200 bar
  • Available with 2 or 4 nozzle configuration
  • Designed for volumetric cleaning under various operating conditions

Installation, Maintenance and Certifications

The RW 200A is easy to install on existing equipment and is designed to ensure long-term reliability.

Maintenance is limited to standard inspection of wear components, thanks to its robust and simplified construction.

Product details
Filter
700 micron
Nozzles
1/4” NPT
Seal materials
NBR – EPDM – VITON
Structure materials
AISI 316
Inlet hole
Ø 162 mm
Rotation speed
15 ÷ 25 rpm
Washing coverage
360°
Weight
9 kg
Max temperature
90 °C
Technical information
Pressure
10 - 200 bar
Flow rate
10 - 200 l/min
Product details
Filter
700 micron
Nozzles
1/4” NPT
Seal materials
NBR – EPDM – VITON
Structure materials
AISI 316
Inlet hole
Ø 162 mm
Rotation speed
15 ÷ 25 rpm
Washing coverage
360°
Weight
9 kg
Max temperature
90 °C
Technical information
Pressure
10 - 200 bar
Flow rate
10 - 200 l/min
