XC035-EEB

Electrical

Volumetric Rotating Tank Cleaning Head with 24V DC Electric Motor

XC035-EEB

Volumetric Rotating Tank Cleaning Head with 24V DC Electric Motor

The XC035-EEB is a volumetric rotating cleaning head designed for cleaning IBC containers, mixers, drums, and preparation tanks, ideal for small and medium-sized closed vessels.


It is particularly suitable for the food, pharmaceutical, cosmetic, and chemical industries, where flexibility, controlled rotation, and process reliability are critical.

Type

Internal

Motorized rotating head, free of oil and grease, washing is performed with 2 or 4 nozzles. Side delivery.

Electrical

Certification

Motor

Why choose XC035-EEB

The XC035-EEB is engineered for cleaning closed containers, featuring a 24V DC electric motor that allows precise selection and maintenance of constant rotational speed.


This ensures:

  • rotation independent of flow rate variations
  • improved control of the cleaning cycle
  • more uniform and repeatable cleaning performance

It is the ideal solution for operators who:

  • require precise control of rotational speed
  • need a versatile and customizable cleaning system
  • work with small and medium closed vessels

Concrete advantages for the operator

  • 24V DC electric motor for controlled rotation
  • Flow rate up to 60 l/min
  • Operating pressure up to 20 bar
  • Customizable lance length
  • Configurable with 2 or 4 nozzles
  • Seal-free nozzle holder for self-cleaning effect

The option to customize lance length and nozzle configuration makes this solution highly flexible and effective. The seal-free nozzle holder reduces critical wear points and enhances self-cleaning performance.

Main Technical Features

  • Operating pressure up to 20 bar
  • Flow rate up to 60 l/min
  • Customizable lance length
  • 2 or 4 nozzle configuration
  • 24V DC electric motor
  • Designed for closed vessels

Installation, Maintenance and Certifications

The XC035-EEB is easy to install on existing equipment and is designed to ensure long-term reliability.


Maintenance is limited to standard inspection of wear components, thanks to its rational and robust construction.

Supplied with:

  • CE certification

If you are looking for a volumetric rotating cleaning head with 24V DC electric motor, adjustable speed, and maximum configuration flexibility, the XC035-EEB provides a versatile and highly controllable technical solution.


The Bolondi team is available to support you in selecting the most suitable configuration or developing custom solutions based on your specific system requirements.

Product details
Nozzles
1/4” NPT
Water inlet
1/2” G
Seal materials
NBR – EPDM – VITON
Bushing materials
PEEK
Structure materials
AISI 316
Inlet hole
Ø 95 mm
Electric motor
24 V AC/DC
Weight
7.5 kg
Max temperature
90 °C
Technical information
Pressure
10 - 20 bar
Flow rate
10 - 60 l/min
Product details
Nozzles
1/4” NPT
Water inlet
1/2” G
Seal materials
NBR – EPDM – VITON
Bushing materials
PEEK
Structure materials
AISI 316
Inlet hole
Ø 95 mm
Electric motor
24 V AC/DC
Weight
7.5 kg
Max temperature
90 °C
Technical information
Pressure
10 - 20 bar
Flow rate
10 - 60 l/min
