XC061-E
Electrical
XC061-E
Volumetric Rotating Cleaning Head with Electric Motor and Full Rotation Control
The XC061-E is a volumetric rotating cleaning head designed for cleaning bins, mixers, preparation vessels, and industrial machinery, ideal for closed containers where effective and controlled internal coverage is essential.
It is particularly suitable for the pharmaceutical, food, cosmetic, and chemical industries, where precision, repeatability, and reliability are critical requirements.
Type
Internal
Motorized or self-rotating rotary head, designed to operate without oils or grease. Cleaning is performed using 2 or 4 nozzles. Equipped with a filter and side inlet for electric and pneumatic versions; coaxial inlet for the water-driven (aquamotor) version.
Electrical
Certification
Motor
Why choose XC061-E
One of the most critical aspects in cleaning closed containers is ensuring correct head positioning and precise rotation control.
The XC061-E addresses both needs:
- Customizable lance length, allowing optimal positioning inside the vessel
- Electric motor with multiple voltage options, ensuring rotation speed is independent of water flow rate
This results in more uniform cleaning and consistent cycle control, even in the presence of pressure or flow variations.
It is the ideal solution for operators who:
- require controlled and constant rotation
- need customizable configurations
- operate in regulated, high-performance environments
Concrete advantages for the operator
- Operating pressure up to 200 bar
- Flow rate up to 60 l/min
- Rotation speed independent of water flow
- Electric motor with multiple voltage options
- Customizable lance based on vessel depth
- Configurable with 2 or 4 nozzles
- Exposed nozzles selected according to application
The ability to customize lance length, nozzle type, and motor voltage makes the XC061-E highly flexible and effective across a wide range of industrial configurations.
Main Technical Features
- Operating pressure up to 200 bar
- Flow rate up to 60 l/min
- Electric motor with multiple voltage options
- Application-specific nozzle selection
- Customizable lance length
- Designed for closed containers and industrial machinery
Installation, Maintenance and Certifications
The XC061-E is easily integrated into existing equipment.
It does not require any lubrication, and maintenance is limited to standard wear components, reducing downtime and operational costs.
Supplied with:
- CE certification
If you are looking for a volumetric rotating cleaning head with electric motor, operating up to 200 bar and offering independent rotation control, the XC061-E provides a precise, flexible, and highly reliable solution.
The Bolondi team is available to support you in selecting the most suitable configuration or developing custom solutions tailored to your process requirements.
Product details | |
|---|---|
Motor | Available electric motors:
24 V AC/DC 0.30 A
48 V 50 Hz 1ph 1.15 A
230 V 50 Hz 1ph 0.23 A
400 V 50 Hz 3ph 0.10 A |
Filter | 700 micron |
Nozzles | 1/8” NPT |
Seal materials | NBR – EPDM – VITON – KALREZ |
Structure materials | AISI 316 |
Inlet hole | Ø 50 mm |
Full cycle duration | 1.2 min at 20 rpm |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 200 bar |
Flow rate | 10 - 60 l/min |
Product details | |
|---|---|
Motor | Available electric motors:
24 V AC/DC 0.30 A
48 V 50 Hz 1ph 1.15 A
230 V 50 Hz 1ph 0.23 A
400 V 50 Hz 3ph 0.10 A |
Filter | 700 micron |
Nozzles | 1/8” NPT |
Seal materials | NBR – EPDM – VITON – KALREZ |
Structure materials | AISI 316 |
Inlet hole | Ø 50 mm |
Full cycle duration | 1.2 min at 20 rpm |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 200 bar |
Flow rate | 10 - 60 l/min |
