XM015-P

Pneumatic

Compact Volumetric Rotating Cleaning Head with Pneumatic Motor

XM015-P

Compact Volumetric Rotating Cleaning Head with Pneumatic Motor

The XM015-P is a compact volumetric rotating cleaning head designed for cleaning small closed containers, ideal when compact size, precise rotation control, and compliance with regulated industry requirements are needed.


It is particularly suitable for the pharmaceutical, food, cosmetic, and chemical industries, where process repeatability and reliability are essential.

Type

Internal

Motorized or self-rotating rotary head, designed to operate without oils or grease. Cleaning is performed at low pressure using 2 or 4 nozzles. Side inlet for electric and pneumatic versions; coaxial inlet for the water-driven (aquamotor) version.

Pneumatic

Certification

Motor

Why choose XM015-P

In small container cleaning, both correct head positioning and rotation stability are crucial. The XM015-P provides:

  • Customizable lance length for optimal positioning inside the container
  • Pneumatic motor, making rotation speed independent of water flow
  • Adjustable air pressure, allowing direct control of rotation speed

This ensures uniform cleaning performance even when available flow rates vary.

It is the ideal solution for operators who:

  • use pumps with flow rates up to 15 l/min
  • need adjustable rotation speed
  • require a compact and controllable system

Concrete advantages for the operator

  • Operating pressure up to 10 bar
  • Flow rate up to 15 l/min
  • Adjustable rotation speed via air pressure
  • Configurable with 2 or 4 nozzles
  • Exposed nozzles selected according to application
  • Customizable lance length
  • Rotation independent from flow variations

The ability to customize lance length and nozzle configuration makes the XM015-P highly flexible and effective, even in specific applications.

Main Technical Features

  • Operating pressure up to 10 bar
  • Flow rate up to 15 l/min
  • Pneumatic motor with adjustable speed
  • Customizable lance length
  • 2–4 nozzle configuration
  • Designed for small closed containers

Installation, Maintenance and Certifications

The XM015-P is easily integrated into existing equipment.


It does not require any lubrication, and maintenance is limited to standard wear components, reducing operational costs and complexity.

Supplied with:

  • CE certification
  • ATEX certification

If you are looking for a compact volumetric rotating cleaning head with pneumatic motor, adjustable speed, and operating pressure up to 10 bar, the XM015-P offers a flexible, controllable, and safety-compliant solution.


The Bolondi team is available to support you in selecting the most suitable configuration or developing customized solutions based on your system requirements.

Product details
Materials
Seals: EPDM – Bushings: PEEK; AISI 316
Inlet hole
2 nozzles Ø57 mm – 4 nozzles Ø66 mm
Full cycle duration
1 min at 3 bar air pressure
Motor
Pneumatic motor from 1 to 6 bar
Weight
7.5 kg
Technical information
Pressure
10 - 10 bar
Flow rate
10 - 80 l/min
Product details
Materials
Seals: EPDM – Bushings: PEEK; AISI 316
Inlet hole
2 nozzles Ø57 mm – 4 nozzles Ø66 mm
Full cycle duration
1 min at 3 bar air pressure
Motor
Pneumatic motor from 1 to 6 bar
Weight
7.5 kg
Technical information
Pressure
10 - 10 bar
Flow rate
10 - 80 l/min
