XB061-E
Electrical
XB061-E
Electrically Driven Volumetric Rotating Tank Cleaning Head for Access Openings ≥ 40 mm
The XB061-E is a volumetric rotating cleaning head with electric motor, designed for cleaning IBC containers, mixers, drums, and preparation tanks where limited access openings must be combined with high performance and full control of rotation.
It is particularly suitable for the food, pharmaceutical, cosmetic, and chemical industries, where reliability, precision, and process repeatability are essential.
Type
Internal
Motorized or self-rotating spherical rotating head, oil and grease-free, washing is performed with 2 or 4 nozzles. With filter and lateral delivery for the electric and pneumatic versions, coaxial delivery for the aquamotor version.
Electrical
Certification
Motor
Why choose XB061-E
The XB061-E is engineered to operate in small and medium closed vessels with access openings ≥ 40 mm, without requiring modifications to existing inlets.
Thanks to the electric motor, available in different voltage options, rotation is independent of water pressure and flow rate. This ensures:
- constant and controlled rotational speed
- improved cleaning uniformity
- high process repeatability
The 39 mm spherical head and the option to customize the lance length make this solution highly versatile.
It is the ideal solution for operators who:
- cannot modify existing inlet openings
- require flow rates up to 60 l/min
- need controlled rotation via electric motor
Concrete advantages for the operator
- Suitable for installation through access openings ≥ 40 mm
- Flow rate up to 60 l/min
- Operating pressure up to 200 bar
- Rotation independent from water flow rate and pressure
- Configurable with 2 or 4 nozzles
- Customizable lance length
The combination of compact design and electric control enables high cleaning performance even in restricted spaces.
Main Technical Features
- Operating pressure up to 200 bar
- Flow rate up to 60 l/min
- 39 mm spherical cleaning head
- Electric motor available in different voltage options
- 2 or 4 nozzle configuration
- Customizable lance length available
Installation, Maintenance and Certifications
The XB061-E is easy to install on existing equipment, even where inlet openings cannot be modified.
Maintenance is limited to standard inspection of wear components, thanks to its compact and rational design.
Supplied with:
- CE certification
If you are looking for a compact volumetric rotating cleaning head with electric motor, capable of delivering up to 60 l/min and operating at pressures up to 200 bar in closed vessels with restricted access, the XB061-E provides a precise and highly versatile technical solution.
The Bolondi team is available to support you in selecting the most suitable configuration or developing custom solutions based on your specific system requirements.
Product details | |
|---|---|
Motor | Available electric motors:
24 V AC/DC 0.30 A
48 V 50 Hz 1ph 1.15 A
230 V 50 Hz 1ph 0.23 A
400 V 50 Hz 3ph 0.10 A |
Filter | 700 micron |
Nozzles | Special XB061 |
Seal materials | NBR – EPDM – VITON |
Structure materials | AISI 316 |
Inlet hole | Ø 50 mm |
Full cycle duration | 1.2 min at 20 rpm |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 200 bar |
Flow rate | 10 - 60 l/min |
Product details | |
|---|---|
Motor | Available electric motors:
24 V AC/DC 0.30 A
48 V 50 Hz 1ph 1.15 A
230 V 50 Hz 1ph 0.23 A
400 V 50 Hz 3ph 0.10 A |
Filter | 700 micron |
Nozzles | Special XB061 |
Seal materials | NBR – EPDM – VITON |
Structure materials | AISI 316 |
Inlet hole | Ø 50 mm |
Full cycle duration | 1.2 min at 20 rpm |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 200 bar |
Flow rate | 10 - 60 l/min |
