XM060-E
Electrical
XM060-E
High-Flow Volumetric Rotating Cleaning Head with Electric Motor
The XM060-E is a volumetric rotating cleaning head designed for cleaning containers, IBCs, mixers, and tanks, ideal for closed vessels where high flow rates, rotation control, and maximum configuration flexibility are required.
It is particularly suitable for the pharmaceutical, food, cosmetic, and chemical industries, with a design compliant with cGMP requirements.
Type
Low pressure
Motorized or self-rotating rotating head, oil and grease-free, low-pressure washing with 2 or 4 nozzles. Side-discharge for electric and pneumatic versions, coaxial discharge for the aquamotor version.
Electrical
Certification
Motor
Why choose XM060-E
In closed-container cleaning, correct positioning of the cleaning head and stable rotation are key factors for achieving effective results.
The XM060-E provides:
- Customizable lance length, ensuring optimal positioning inside the vessel
- Electric motor with a wide range of voltage options, making rotation speed independent of water flow
- Adjustable and constant rotation speed, tailored to process requirements
With a flow rate up to 80 l/min, it is particularly suitable for applications requiring higher water volumes while maintaining precise motion control.
Concrete advantages for the operator
- Operating pressure up to 10 bar
- Flow rate up to 80 l/min
- Controlled rotation speed
- Electric motor independent from flow variations
- Customizable lance based on container depth
- Configurable with 2 or 4 nozzles
- Exposed nozzles selected according to application
- Self-cleaning system
- cGMP-compliant design
The ability to customize lance length and nozzle configuration makes the XM060-E highly flexible and effective across a wide range of industrial applications.
Main Technical Features
- Operating pressure up to 10 bar
- Flow rate up to 80 l/min
- Electric motor with multiple voltage options
- Customizable lance length
- 2–4 nozzle configuration
- Self-cleaning structure
Installation, Maintenance and Certifications
The XM060-E is easily integrated into existing equipment.
It does not require any lubrication, and maintenance is limited to standard wear components, reducing operational costs and system complexity.
Supplied with:
- CE certification
If you are looking for a volumetric rotating cleaning head with electric motor, flow rate up to 80 l/min, and rotation speed independent from water flow, the XM060-E provides a powerful, flexible, and regulation-compliant solution.
The Bolondi team is available to support you in configuring the most suitable solution or developing customized versions based on your system requirements.
Product details | |
|---|---|
Nozzles | M12×1 |
Seal materials | EPDM |
Bushing materials | PEEK |
Structure materials | AISI 316 |
Inlet hole | Ø 120 mm |
Full cycle duration | 1.4 min |
Motor | Available electric motors:
24 V AC/DC 0.30 A
48 V 50 Hz 1ph 1.15 A
230 V 50 Hz 1ph 0.23 A
400 V 50 Hz 3ph 0.10 A |
Weight | 7.5 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 10 bar |
Flow rate | 10 - 80 l/min |
Product details | |
|---|---|
Nozzles | M12×1 |
Seal materials | EPDM |
Bushing materials | PEEK |
Structure materials | AISI 316 |
Inlet hole | Ø 120 mm |
Full cycle duration | 1.4 min |
Motor | Available electric motors:
24 V AC/DC 0.30 A
48 V 50 Hz 1ph 1.15 A
230 V 50 Hz 1ph 0.23 A
400 V 50 Hz 3ph 0.10 A |
Weight | 7.5 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 10 bar |
Flow rate | 10 - 80 l/min |
