XM060-P
Pneumatic
XM060-P
High-Flow Volumetric Rotating Cleaning Head with Pneumatic Motor
The XM060-P is a volumetric rotating cleaning head designed for cleaning containers, IBCs, mixers, and tanks, ideal for closed vessels where high flow rates and precise rotation speed control are required.
It is particularly suitable for the pharmaceutical, food, cosmetic, and chemical industries, with a design compliant with cGMP requirements.
Type
Low pressure
Motorized or self-rotating rotary head, designed to operate without oils or grease. Cleaning is performed at low pressure using 2 or 4 nozzles. Side inlet for electric and pneumatic versions; coaxial inlet for the water-driven (aquamotor) version.
Pneumatic
Certification
Motor
Why choose XM060-P
In closed-container cleaning, correct head positioning and stable rotation are essential to achieve uniform and effective results.
The XM060-P provides:
- Customizable lance length for optimal positioning inside the vessel
- Pneumatic motor, making rotation speed independent of water flow
- Adjustable air pressure, allowing precise control of rotation speed according to operational needs
With a flow rate up to 80 l/min, it is well suited for applications requiring high water volumes while maintaining consistent rotation control.
Concrete advantages for the operator
- Operating pressure up to 10 bar
- Flow rate up to 80 l/min
- Adjustable rotation speed via air pressure regulation
- Rotation independent from flow variations
- Configurable with 2 or 4 nozzles
- Exposed nozzles selected according to application
- Self-cleaning system
- cGMP-compliant design
The ability to customize lance length and nozzle configuration makes the XM060-P highly flexible and effective, even in complex system installations.
Main Technical Features
- Operating pressure up to 10 bar
- Flow rate up to 80 l/min
- Pneumatic motor with adjustable speed
- Customizable lance length
- 2–4 nozzle configuration
- Self-cleaning structure
Installation, Maintenance and Certifications
The XM060-P is easily integrated into existing equipment.
It does not require any lubrication, and maintenance is limited to standard wear components, ensuring long-term reliability and reduced operating costs.
Supplied with:
- CE certification
- ATEX certification
If you are looking for a volumetric rotating cleaning head with pneumatic motor, flow rate up to 80 l/min, and adjustable rotation speed via compressed air pressure, the XM060-P offers a powerful, flexible, and safety-compliant solution.
The Bolondi team is available to support you in configuring the most suitable solution or developing customized versions based on your system requirements.
Product details | |
|---|---|
Nozzles | M12×1 |
Seal materials | EPDM |
Bushing materials | PEEK |
Structure materials | AISI 316 |
Inlet hole | Ø 120 mm |
Full cycle duration | 0.6 min at 3 bar air pressure |
Motor | Pneumatic motor from 1 to 6 bar |
Weight | 7.5 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 10 bar |
Flow rate | 10 - 80 l/min |
Product details | |
|---|---|
Nozzles | M12×1 |
Seal materials | EPDM |
Bushing materials | PEEK |
Structure materials | AISI 316 |
Inlet hole | Ø 120 mm |
Full cycle duration | 0.6 min at 3 bar air pressure |
Motor | Pneumatic motor from 1 to 6 bar |
Weight | 7.5 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 10 bar |
Flow rate | 10 - 80 l/min |
