XM200-A
Acquamotor
XM200-A
Ultra High-Flow Volumetric Self-Rotating Cleaning Head with Water-Driven Motor
The XM200-A is a volumetric self-rotating cleaning head designed for cleaning closed containers, IBCs, mixers, and tanks, ideal when very high flow rates at low pressure and maximum system simplicity are required.
It is particularly suitable for the pharmaceutical, food, cosmetic, and chemical industries, with a design compliant with cGMP requirements.
Type
Low pressure
Motorized or self-rotating rotating head, oil and grease-free, low-pressure washing with 2 or 4 nozzles. Side-discharge for electric and pneumatic versions, coaxial discharge for the aquamotor version.
Acquamotor
Certification
Motor
Why choose XM200-A
In many industrial applications, it is essential to handle large volumes of water without increasing system complexity.
The XM200-A:
- is powered by a water-driven motor (aquamotor)
- requires no electrical or pneumatic supply
- operates at low pressure (up to 10 bar)
- handles flow rates up to 200 l/min
This allows high-flow volumetric dynamic cleaning using only pressurized water.
Concrete advantages for the operator
- Operating pressure up to 10 bar
- Flow rate up to 200 l/min
- Powered exclusively by pressurized water
- Configurable with 2 or 4 nozzles
- cGMP-compliant design for pharmaceutical applications
- No external energy source required
The absence of electric or pneumatic motors reduces wiring, connections, and potential system issues, making the solution extremely reliable.
Main Technical Features
- Operating pressure up to 10 bar
- Flow rate up to 200 l/min
- Water-driven motor (aquamotor)
- 2–4 nozzle configuration
- Designed for regulated industry applications
Installation, Maintenance and Certifications
The XM200-A is easily integrated into existing equipment.
It does not require any lubrication, and maintenance is limited to standard wear components, ensuring operational continuity and reduced costs.
Supplied with:
- CE certification
If you are looking for a volumetric self-rotating cleaning head with flow rate up to 200 l/min, low-pressure operation, and no external power supply, the XM200-A offers a powerful, simple, and highly reliable solution.
The Bolondi team is available to support you in configuring the most suitable solution or developing customized versions based on your operational requirements.
Product details | |
|---|---|
Nozzles | M16×1 |
Seal materials | EPDM |
Bushing materials | PEEK |
Structure materials | AISI 316 |
Inlet hole | Ø 185 mm |
Full cycle duration | 1 min at 20 rpm |
Motor | Water-driven motor |
Weight | – |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 10 bar |
Flow rate | 3 - 200 l/min |
Product details | |
|---|---|
Nozzles | M16×1 |
Seal materials | EPDM |
Bushing materials | PEEK |
Structure materials | AISI 316 |
Inlet hole | Ø 185 mm |
Full cycle duration | 1 min at 20 rpm |
Motor | Water-driven motor |
Weight | – |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 10 bar |
Flow rate | 3 - 200 l/min |
