XM200-P
Pneumatic
XM200-P
Pneumatic Volumetric Rotating Cleaning Head for Controlled Cleaning of Closed Containers
In internal container cleaning, one of the most critical aspects is maintaining a constant and controllable rotation speed, even when system conditions vary.
The XM200-P is designed to ensure this level of control, thanks to its pneumatic drive, which makes performance completely independent from water flow rate.
Type
Low pressure
Motorized or self-rotating rotating head, oil and grease-free, low-pressure washing with 2 or 4 nozzles. Side-discharge for electric and pneumatic versions, coaxial discharge for the aquamotor version.
Pneumatic
Certification
Motor
Why choose XM200-P
The key strength of the XM200-P lies in the ability to precisely control rotation speed by directly adjusting air pressure.
This results in:
- stable performance even with flow variations
- direct and immediate control of the cleaning cycle
- improved uniformity of results
- adaptability to different operating conditions
It is the ideal solution for systems where flexibility and control are essential, particularly in the pharmaceutical, food, cosmetic, and chemical industries.
Ideal Applications
The XM200-P is specifically designed for internal cleaning of:
- closed containers
- IBCs (Intermediate Bulk Containers)
- mixers
- tanks and vessels
It is particularly effective in applications where uniform and repeatable coverage of all internal surfaces is required.
Concrete advantages for the operator
Unlike traditional solutions, the XM200-P allows operators to:
- adjust rotation speed via air pressure
- adapt cleaning performance based on residue type or processed product
- maintain consistency even with hydraulic variations
This level of control makes the system highly versatile and reliable.
Main Technical Features
- Operating pressure: up to 10 bar
- Flow rate: up to 200 l/min
- Pneumatic motor with adjustable air pressure
- Configuration with 2 or 4 nozzles
- cGMP-compliant design
- CE and ATEX certifications
Installation, Maintenance and Certifications
If you operate in environments requiring high safety standards and strict process control, the XM200-P offers a unique combination of:
- precision
- adaptability
- safety
Contact the Bolondi Team
Every system has specific requirements. The Bolondi team can support you in:
- configuring the XM200-P according to your process
- evaluating alternative technical solutions
- developing fully customized systems
Contact the Bolondi team to find the most effective cleaning solution for your application
Product details | |
|---|---|
Nozzles | M16×1 |
Seal materials | EPDM |
Bushing materials | PEEK |
Structure materials | AISI 316 |
Inlet hole | Ø 185 mm |
Full cycle duration | 1.5 min at 4 bar air pressure |
Motor | Pneumatic motor from 1 to 6 bar |
Weight | 7.5 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 10 bar |
Flow rate | 3 - 200 l/min |
Product details | |
|---|---|
Nozzles | M16×1 |
Seal materials | EPDM |
Bushing materials | PEEK |
Structure materials | AISI 316 |
Inlet hole | Ø 185 mm |
Full cycle duration | 1.5 min at 4 bar air pressure |
Motor | Pneumatic motor from 1 to 6 bar |
Weight | 7.5 kg |
Max temperature | 90 °C |
Technical information | |
|---|---|
Pressure | 10 - 10 bar |
Flow rate | 3 - 200 l/min |
